The MCT Samatic 5000IR is a rotary insert-grinding machine designed for PDC, CBN, and Carbide round inserts grinding especially for the oil drilling industry.
The Samatic 5000IR is a 7 axis with 5 axis CNC controlled grinding machine. It provides 7 axis of freedom of movement and adjustment to accomplish a variety of PDC, CBN, Carbide indexable inserts tool geometry grinding.
The Samatic 5000IR is equipped with an automatic measuring system that is capable of grinding multiple operations to the specified dimension automatically.
The Samatic 5000IR doesn’t just come with precision, flexibility, intelligence, and ease of use, it also comes with a cost-effective low price!
The video on the right hand side demonstrates the Samatic 5000IR machine is grinding PDC tipped end mills.
Technical Specifications
| Model | Samatic 5000IR |
|---|---|
| CNC Axis | 5 |
| Drive System | DC motor |
| Work Head RPM | 400 RPM max |
| Spindle Power | 5 HP (5,000 RPM) 220 VAC 3 phase |
| System Power | 110 VAC 1,200 W |
| Dimensions | 6’ W 5’ D 6.5’ H |
| Weight | 3,500 lbs. |
