The MCT Samatic 5000I CNC controlled PDC insert grinder provides 7 axis freedom of movement and adjustment to accomplish a variety of PDC, CBN, carbide indexable inserts tool geometry grinding.
The Samatic 5000I is equipped with an automatic measuring system that is capable of grinding multiple operations of your PDC inserts to the specified dimension automatically. The Samatic 5000I doesn’t just come with precision, flexibility, intelligence, and ease of use, it also comes with a cost-effective low price!
The video on the right hand side demonstrates the Samatic 5000I machine is grinding PDC tipped indexable inserts with a 0.016” of corner radius.
Technical Specifications
| Model | Samatic 5000I |
|---|---|
| CNC Axis | 5 |
| Drive System | DC motor |
| Work Head RPM | 400 RPM max |
| Spindle Power | 5 HP (5,000 RPM) 220 VAC 3 phase |
| System Power | 110 VAC 1,200 W |
| Dimensions | 6’ W 5’ D 6.5’ H |
| Weight | 3,500 lbs. |
